CAT 6A RISER (CMR) – UNSHIELDED

23 AWG Cat6A CMR, Twisted Pair, High-Performance Data Cable with Spline; 10G

DESCRIPTION

23 AWG Cat6A CMR, Twisted Pair, High-Performance Data Cable with Spline; 10G

STANDARDS

• UL Verified Type CMR
• c(UL) listed FT4
• ANSI/TIA-568-C.2
• ISO/IEC 11801
• RoHS Compliant
• ATM 155 Mbps
• 10/100/1000/10G Base-T (IEEE 802.3)
• 4/16 Mbps Token Ring (IEEE 802.3)
• 100 Mbps TP-PMD
• ISDN, ADSL
• ATM LAN 1.2G
• Horizontal Distribution & Backbone Cabling

PART NUMBER

8130-6A

CONDUCTOR MATERIAL

SOLID ANNEALED BARE COPPER

NUMBER OF CONDUCTOR PAIRS

AWG SIZE

STRANDING

SOLID

INSULATION COLOR CODE

PAIR 1 (White/Blue & Blue); PAIR 2 (White/Orange & Orange); PAIR 3 (White/Green & Green); Pair 4 (White/Brown & Brown)

JACKET COLORS

Blue, White, Green, Grey, Yellow, Red

INSULATION MATERIAL

HDPE

OVERALL DIAMETER (INCHES)

.315 IN. ± .002 IN.

AVERAGE THICKNESS (INCHES)

0,0086

JACKET MATERIAL

FLAME RETARDANT PVC

AVERAGE WALL THICKNESS (INCHES)

0,022

NOMINAL OUTER DIAMTER (INCHES)

.3IN. ± .008 IN.

NOMINAL WEIGHT (LBS/KFT)

SHIELD MATERIAL

UNSHIELDED

RIPCORD

YES

TEMPERATUR RATING (INSTALLATION)	0°C to + 60°C
TEMPERATURE RATING (OPERATING)	-20°C to + 75°C
TENSILE STRENGTH (BEFORE)	>=13.8 Mpa
ELONGATION (AGING)	>=100%
AGING CONDITION	100°C X 168 hours
AGING CONDITION (AFTER)	>=85% OF UNAGED
AGING CONDITION (AGING)	>=50% OF UNAGED
MAX CONDUCTOR DC RESISTANCE @ 20°C	6.85 Ω / 100 FT
MAX DC RESISTANCE UNBALNCED @ 20°C	5,0%
MAX. PAIR TO PAIR GROUND CAPACITANCE UNBALANCE	330 pF / 100 Meter
CHARACTERISTIC IMPEDANCE (1 - 350 MHz)	≤100 ± 15 Ω
MUTUAL CAPACITANCE	5.6 nF / 100 ft Nominal
MAX. DELAY SKEW	40 nS / 100 Meters
VELOCITY OF PROPAGATION	65%
