16 AWG 3 C RISER – UNSHIEDLED

16 AWG 3 conductor 19 strand bare copper wire with PVC insulation, unshielded and overall PVC jacket for low-voltage electronic cable applications.

DESCRIPTION

16 AWG 3 conductor 19 strand bare copper wire with PVC insulation, unshielded and overall PVC jacket for low-voltage electronic cable applications.

STANDARDS

• Refer to NEC (NFPA 70) article 725 and article 800 for installation guidelines
• UL listed as type CL3R per UL standard 13 and as type CMR c(UL)us 75°C per UL standard 444
• All materials used in the manufacture of this cable are RoHS compliant
• Made in the USA

PART NUMBER

4150

JACKET COLOR

GRAY

JACKET

POLYVINYLCHLORIDE

CONDUCTORS

16 AWG 19 STRANDS CLASS C; ANNEALED BARE COPPER

COLOR CODE

BLACK, RED, WHITE

INSULATION

POLYVINYLCHLORIDE

SHIELD

NONE

RIPCORD

YES

AWG

16

CONDUCTOR

3

STRANDING

19

NOMINAL LAY LENGTH (LHL - INCHES)

2.5

INSULATION THICKNESS (INCHES)

0.007

JACKET WALL THICKNESS (INCHES)

0.015

OVERAL DIAMETER (INCHES)

0.186

NET WEIGHT

35

VOLTAGE

300
